AMT 1626-022-00 Motor - 3/4 HP Volts TEFC

The AMT 1626-022-00 is a Motor, 3/4 Horsepower, 1725 RPM, Volts, 3 Phase, TEFC Totally Enclosed Fan Cooled, 60/50 Hz, Nema 56J Frame, replacement electric motor only for an AMT Pump. MOTOR REPLACEMENT Entire pump end must be disassembled before removing motor from adapter and stub shaft. 1. Remove pump casing, impeller, shaft seal, and seal plate as described in SHAFT SEAL REPLACEMENT section. 2. Remove fasteners connecting adapter to motor . 3. Remove adapter from motor. 4. Loosen fasteners of shaft clamp . Remove shaft clamp, stub shaft , and drive key from motor shaft. 5. Reverse procedure, reassemble pump on replacement motor. 6. Set distance from motor end bell mounting face to stub shaft shoulder to 2.75. 7. Securely tighten shaft clamp fasteners locking stub shaft in position.
