AMT 2200-006-90 Impeller - Bronze

The AMT 2200-006-90 is a 1P295 Impeller Assembly, Bronze for an AMT Bronze Coolant Recirculating Pump. IMPELLER MOTOR REPLACEMENT PROCEDURE 1. Remove base volute housing by removing three mounting screws . 2. Remove impeller from impeller tubing . If it doesnt come off easily, cut it off. 3. Unscrew motor adapter from motor exposing impeller tube without impeller. 4. Cut tubing of impeller assembly diagonally so that it comes off motor shaft. Do not cut motor shaft. 5. When replacing a new motor, a new impeller assembly must also be installed. 6. Reassemble pump parts back onto motor, tightening screws into place. 7. Before pressing impeller assembly onto shaft, insert a piece of metal to hold motor shaft from being pressed out. 8. Turn motor around onto fixture and press impeller assembly onto shaft using tool with guide pin that fits into impeller tube. Press unit in until there is enough room so it touches neither the volute nor the volute cover while running. 9. Turn unit on momentarily to see if unit vibrates. If it does, insert a screwdriver into impeller assembly and bend slightly. Retest to see if vibration is still there. If it has increased bend op
