Danfoss part # 180L0128 VDHT Solenoid operated valve
Danfoss # 180L0128
Danfoss catalog # 180L0128, VDHT Solenoid operated valve, with 1/2 inch NPT ports, straight flow, normally closed, high pressure variant, rated for a flow of 16 GPM, and max pressure of 3000 PSI.
Price : $ 773.32
Product Information :
The Danfoss part # 180L0128 is a VDHT Solenoid operated valve, with 1/2 inch NPT ports, straight flow, normally closed, high pressure variant, rated for a flow of 16 GPM, and max pressure of 3000 PSI. . The VDHT valve series are designed for several applications in neutral media compatible with the sealing and O-ring materials used. Typical media are water, cleaning fluids and light heating oil. The directional valves are pilot operated ON/OFF seat valves electrically activated by a coil. The valve housing, blocks and manifolds are made of stainless steel AISI 304 Stainless Steel, and the piston of stainless steel AISI 316 Stainless Steel. Standard valves are delivered with PTFE piston and FPM sealings.
