Jabsco # 12510-0003 Bronze Self Priming Pump And Motor 1/6 HP
Jabsco # 12510-0003
Jabsco catalog # 12510-0003, Bronze Self Priming Pump And Motor and Motor unit. Bronze Construction, with a Nitrile Impeller and Lip Type Seal. Pump is Close Coupled to a 1/6 Horsepower, 115 Volts, ODP (Open Drip Proof) Motor. Comes with a 8 foot Cord 3 Prong Grounded Plug. Ports are 3/8 Inch NPT Internal and 3/4 Inch GHT External.
Price : $ 879.26
Product Information :
Parts Page (click here)
Product Manual PDF (view)The Jabsco 12510-0003 is a bronze Flexible Impeller pump with a Nitrile Impeller, Lip Type seal, coupled to a 1/6 Horsepower, 115 Volts, ODP, 60 HZ Motor, with a 8 foot Cord and 3 Prong Grounded Plug. This pump has a nominal flow rate of 2.7 GPM (10.2 LPM), and is self-priming from dry up to 6 feet (2m) and a lift to 20 feet (6m) when primed. Be sure suction lines are airtight or pump will not self-prime. The Nitrile impeller in this pump is good for oil-based products. Temperature limits for Nitrile impellers are 50 degrees to 180 degrees F (10 degrees to 82 degrees C). This unit depends on liquid pumped for lubrication. Do Not Run Dry for more than 30 seconds. Lack of liquid will damage the impeller and the pump components.
Features :
Product Specs :
2.7 GPM output at 10' total head.
Continuous duty motor with thermal overload protection.
8 foot power cord with three prong plug.
Convenient carrying handle.
Easy to service and maintain.
Will tolerate abrasive wear.
Handles hard and soft solids without clogging.
Non pulsating flow.
Parts and Accessories for Jabsco model 12510-0003
Major Overhaul Kit / Rebuild Kit :
Catalog # 90106-0013, Service Kit, Nitrile, with Nitrile Impeller, Seal and Gasket
Price: $ 62.51
Impeller :
Catalog # 9200-0003, Impeller, Nitrile, with Brass Insert
Price: $ 52.01
Applications
These pumps are versatile, multipurpose units that fill in where more specialised and expensive units are not practical for the job in hand. This Jabsco flexible impeller pump combines the priming feature of positive displacement type pumps with the general transfer ability of centrifugals. It will pump either thin or viscous liquids and can handle more solids in suspension than other types of rotary pumps. It operates at low or high speeds, can be mounted at any angle and pumps in either direction with equal efficiency. Typical applications for this pump include INDUSTRIAL Circulating and transferring, velocitymixing, pumping machine tool coolants, return spill, sump drainage, pharmaceuticals, soap, liquors, ink, dyes, alcohol, glycerine, brine and pumping water for cooling heliarc welding equipment. FARMING Pumping water for stock, pumping water from shallow wells and cisterns. MARINE Washdowns, utility dock side pump. PLUMBING and HOME EMERGENCY USE Pumping out flooded basements, cesspools, sumps, water heaters and water closets, drains and sinks, draining fishponds and small pools. PUBLIC UTILITIES AND MUNICIPALITIES Dewatering and draining meter boxes and excavations, dust control and sampling.
